201 Puckett Ferry Rd Bldg G

Parcel ID

6877-675-791

Office Space

11,750 SF

Office/Breakroom/Locker

8,831 SF

Clear Height

23’ Clear in Manufacturing Area | 14’ 8” Clear in the Drop Ceiling Area

Column Width/Depth

30’ x 50’

Floors

6” Reinforced Concrete Slab

Walls

2” Insulated Metal Sandwich Panel

Roof

Single-Ply Membrane Over Insulated Metal Deck

Lighting

T-8

Power

Supplied by Duke Energy; 4160 Volts | Two 1200-Amp Breakers at 4160 Volts | One @ 1500 KVA (4160 - 480/277) & One @ 750 KVA (4160 - 120/208) Transformers

Fire Safety

.17/3000 to .45/2500 Depending On Area | Warehouse is K14 @ 50 PSI ESFR

Dock Doors

Ten 8’ x 10’ Electric Dock High Doors with Levelers, Locks, Seals, & Lights | One 10’ x 10’ Manual Drive-In Door

Parking

70 Spaces; More Available from Shared Lot with P Plant

Restrooms

2 Men’s | 2 Women’s

Water

Supplied by Greenwood CPW; 8” Main, 6” Line, 100 PSI

Sewer

Supplied by Greenwood CPW; 18” Main, One 8” Line, Three 6” Lines

Natural Gas

Supplied by Greenwood CPW, 4” Line, 5 PSI

Compressed Air

One Atlas Copco Z122 (8.6 Bar, 22 KW, 2018) | One Gardner Denver (100 PSI, 30 HP, 2006) | One Atlas Copco ZR-15 (125 PSI, 60 HP, 1996)

Chillers

Two 150-Ton Trane Chillers Provide Primary Cooling & One 100-Ton Roof Mounted York Unit Serves the Class 6 Clean Room

Boilers

Cleaver-Brooks & Hurst Fueled by Natural Gas | Two Hot Water (30 HP), Two Steam (60 HP) | Cleaver-Brooks Hot Water - 25 Years | Cleaver-Brooks Steam - 3 Years | Hurst Steam - 21 Years

Rooftop Units

12 Trane Intellipack & Voyager 10- to 30-tons (25 years old) | The Roof-Mounted HVAC Enclosure is Approx. 49’ x 207’ & Houses Multiple Air Handlers
